ELECROW ESP32S WIFI BLE Board- V1.0

Availability:

In stock


SKU: 1855144
  1. Model: ELECROW ESP32S WIFI BLE Board- V1.0
  2. Versatile Module
  3. Dual-Core
  4. Ample Peripherals
  5. Connectivity
  6. Power Efficiency
  7. High Data Rates
  8. Security Features
  9. Additional Features

For bulk orders or B2B inquiries, email us: sales@robu.in

 1,139.00 (Incl. GST)

In stock

Purchase this product now and earn 12 Robu Points!

Very Low Stock. Order Now !


Free Delivery above ₹499
Free Delivery
above ₹499
1 Year Warranty
6 Months Warranty
Cash On delivery
Cash on Delivery*

Didn’t find what you are looking for?

Brand: ELECROW
Category: Other ESP WIFI Modules
Tags: wifi module

ESP-WROOM-32 is a versatile Wi-Fi+BT+BLE MCU module by Espressif, tailored for diverse applications from sensor networks to complex tasks like voice encoding and music streaming. Featuring a dual-core CPU running at 160MHz, it offers ample pins and peripherals. With Wi-Fi for internet connectivity and Bluetooth for device pairing, it’s future-proof. Boasting a sleep current under 5 µA, it’s ideal for battery-powered devices. Supporting data rates up to 150 Mbps, it excels in performance, power efficiency, and connectivity.


Features:

  1. Support SD card, UART, SPI, SDIO, I2C, LED PWM, Motor PWM,I2S, I2C, IRUSB-UART
  2. Integrated 802.11 BGN WiFi transceiver and dual-mode Bluetooth (classic and BLE)
  3. Hardware accelerated encryption (AES, SHA2, ECC, RSA-4096)
  4. Integrated LiPo Battery Charger.
  5. 10-electrode capacitive touch support
  6. Up to 240MHz clock frequency and 520kB internal SRAM
  7. Support Station/SoftAP/SoftAP+Station/P2P
  8. Support WPA/WPA2/WPA2-Enterprise/WPS
    include bridge, reset- and boot-mode buttons, LDO regulator and a micro-USB connector.
    Support AES/RSA/ECC/SHA
  9. A- MPDU and A-MSDU aggregation and 0.4 _s guard interval support
  10. Radio: NZIF receiver with -98 dBm sensitivity, Class-1, class-2 and class-3 transmitter

Package Includes:

1 x ELECROW ESP32S WIFI BLE Board- V1.0

SKU: 1855144 Category: Tag:
Item Type:

WiFi Module

Based On:

ESP32 Based

Model No.:

ELECROW ESP32S WIFI BLE Board- V1.0

WIFI

802.11 b/g/n/e/i (802.11n up to 150 Mbps)

Frequency Range:

2.4 ~ 2.5 GHz

Bluetooth Version:

Bluetooth 4.2 BR/EDR and BLE standards

Audio

CVSD and SBC

On-board clock

40 MHz crystal

Operating Voltage (V)

2.2 ~ 3.6

Operating Current (mA)

80

Operating Temperature (°C)

-40~85℃

Shipping Weight 0.010 kg
Shipping Dimensions 10 × 8 × 3 cm
